| Technical Specification | |
| General | |
| Inputs | 2 |
| Input Impedance | > 10k Ohm Electronically balanced |
| Maximum Input level | +20dBu |
| Outputs | Four [LMS-4] or Six [LMS-6] |
| Output Impedance | <100 Ohm, ground balanced |
| Maximum Output Level | +20dBu into 600ohm load |
| Sample Rate | 96kHz |
| Bit Depth | 24 bit |
| Frequency Response | 10Hz to 40kHz, +/- 3dB (Filters Disabled) |
| 20Hz to 20kHz, +/- 0.5dB (Filters Disabled) | |
| THD | <0.01%, (+10dBu, 20Hz to 20kHz, 30kHz bandwidth) |
| Dynamic Range | >112dB (A weighted, 22kHz bandwidth) |
| >109dB (un-weighted, 22kHz bandwidth) | |
| Serial Comms Data | 38.4kbaud, format: 8 data, 1 stop, no parity |
| Processing | |
| Gain | +20dB to -80dB and mute, 0.2dB steps |
| Output Ch. Source | Input A, Input B and SUM |
| HP filter frequency | Off, 10Hz to 25.4kHz, 1/36 octave steps |
| LP filter frequency | 10Hz to 25.4kHz and off, 1/36 octave steps |
| LP / HP filter type | 12, 18 & 24dB/octave Bessel and Butterworth |
| 12, 24 and 48dB/octave Linkwitz Riley | |
| 4th or 8th order Hardman | |
| Delay | Input 400ms, output 80ms |
| Limiter | High performance limiter, adjustable threshold in 0.2dB steps, automatic time constants |
| EQ Frequency | 10Hz to 25kHz, 1/36 octave steps |
| EQ Gain | +15dB to -15dB, 0.2dB steps |
| EQ Width | 5.0 to 0.1 octaves bandwidth, 1/36 octave steps |
| Connectors | |
| Audio inputs | 3 pin female XLR |
| Audio outputs | 3 pin male XLR |
| Serial comms | Future option |
| Network comms | Future option |
| Mains | 3 pin IEC |
| Mains Power | Universal switch-mode PSU, 85v to 250v AC, 50 / 60Hz |
| Consumption | < 25watts |
| Dimensions | 44mm (H), 482mm (W), 254mm (D) |
| Weight | 2.7 Kgs net |
Continued R&D leads to innovation & improvements.
In the light of implementing such improvements, emPad reserves the right to change published specifications and parameters without prior notice.
